Heat Transfer From A Pin-Fin

Heat Transfer From A Pin-Fin

The setup is designed to study the heat transfer in a pin fin. It consists of pin type fin fitted in duct. A fan is provided on one side of duct to conduct experiments under forced draft conditions. Airflow rates can be varied with the help of damper provided in the duct. A heater heats one end of fin and heat flows to another end. Heat input to the heater is given through Variac. Digital Temperature Indicator measures temperature distribution along the fin.

Specifications:

 Fins-12 mm

 OD-100 mm long, with 5 thermo-couples along the length

 Heater- Band heater to heat one end of fin

 Airflow duct- 100 mm. X 150 mm and ½ mtr. Long, connected at suction of blower and is provided with bell mouth entry

 Centrifugal blower of variable speed of suitable capacity provided with orifice and water manometer

CONTROL PANEL:

1.12 Channel Digital Temperature Indicator

2. Dimmerstat : 0 – 2 A.

3. Main’s on/Off Switch.

4. Voltmeter: 0 – 250 V.

5. Ammeter: 0 – 3 A.

6. Blower On/Off Switch.

Reviews

There are no reviews yet.

Be the first to review “Heat Transfer From A Pin-Fin”

Your email address will not be published. Required fields are marked *

Experiment

Experiments

  • To study the temperature distribution along the length of a pin fin in natural & forced convection.
  •   To calculate Gr, Per & Nu number in natural conviction.
  •   Calculate Re, Per & Nu number in forced conviction.
  •   Calculate the value of m & obtain the temperature at various locations along the length of the fin in natural forced conviction.
  •   Calculate the values of heat transfer rate from the fin & the fin effectiveness in natural & forced conviction.
  •   The experiments can be conducted at various values of input & calculation can be made accordingly.
  •   Heat Transfer from Pin – Fin Apparatus

Requirement

  • Electricity Supply: 1 Phase, 220 V AC, 5 Amp.
  • Table for set-up support
