Induction Coil – Physics Laboratory Equipment

Induction Coils are wound from insulated copper wire and paraffin wax insulation is provided throughout with condenser, in polished case. A fully adjustable trembler system is incorporated spark suppression capacitors are housed in a base. A pair of pointer electrodes are supplied with the instrument, the pointer electrode having an insulating handle for adjustment of the spark gap. Low voltage input is via a pair of baseboard mounted 4 mm. Sockets.

An Induction coil or “spark coil”  is a type of electrical transformer used to produce high-voltage pulses from a low-voltage direct current (DC) supply

Sensitive to be used with kohlraush Conductivity Bridge

• In cabinet polish wooden box.
• Coils are made from best quality enamelled copper wire and paraffin insulaion is provided throughout.
• Fitted with platinum contact with removable spark discharger.
• Complete with ON/OFF switch of primary and two bakelite look type terminals.
• Coils upto 15mm spark length are workable on 4-6 volts and rest on 6-12 volts DC.

Available in Spark length: 10mm, 15mm, 20mm, 25mm, 75mm, 100mm
