Meter Bridge-Resistance of a wire Experiment


Categories: , Tags: , , , ,


Meter Bridge-Resistance of a wire Experiment

Meter Bridge-Resistance of a wire Experiment

Our Objective:

To find the resistance of a given wire using a metre bridge and hence determine the specific resistance of its materials.

Theory

Wheatstone’s principle

The metre bridge is operates under Wheatstone’s principle.  Here, four resistors P, Q, R, and S are connected to form the network ABCD. The terminals A and C are connected to a battery, and the terminals C and D are connected to a galvanometer through keys K1 and K2 respectively.                                                                                                                                                                                          In the balancing condition, there is no deflection on the galvanometer. Then,



Meter Bridge apparatus

The meter bridge, also known as the slide wire bridge consists of a one metre long wire of uniform cross sectional area, fixed on a wooden block. A scale is attached to the block. Two gaps are formed on it by using thick metal strips in order to make the Wheat stone’s bridge. The terminal B between the gaps is used to connect galvanometer and jockey.



A resistance wire is introduced in gap S and the resistance box is in gap R. One end of the galvanometer is connected to terminal D and its other end is connected to a jockey. As the jockey slides over the wire AC, it shows zero deflection at the balancing point (null point).

If the length AB is , then the length BC is  ( 100-).

Then, according to Wheatstone’s principle;



Now, the unknown resistance can be calculated as,



The specific resistance or resistivity of the material of the wire can be then calculated by using the relation,

; Where L be the length of the wire and r be its radius.

Reviews

There are no reviews yet.

Be the first to review “Meter Bridge-Resistance of a wire Experiment”

Your email address will not be published. Required fields are marked *

Experiment

Meter Bridge apparatus

The meter bridge, also known as the slide wire bridge consists of a one metre long wire of uniform cross sectional area, fixed on a wooden block. A scale is attached to the block. Two gaps are formed on it by using thick metal strips in order to make the Wheat stone’s bridge. The terminal B between the gaps is used to connect galvanometer and jockey.



A resistance wire is introduced in gap S and the resistance box is in gap R. One end of the galvanometer is connected to terminal D and its other end is connected to a jockey. As the jockey slides over the wire AC, it shows zero deflection at the balancing point (null point).

If the length AB is , then the length BC is  ( 100-).

Then, according to Wheatstone’s principle;



Now, the unknown resistance can be calculated as,



The specific resistance or resistivity of the material of the wire can be then calculated by using the relation,

; Where L be the length of the wire and r be its radius.
Learning Outcomes:

  • Students understand Wheatstone’s bridge and Wheatstone’s principle.
  • Students verify Wheatstone’s principle.
  • Students correlate the principle of Whetstone’s bridge with meter bridge experiment
